Ag-Bag MB10012HyPac User Manual
Page 17
17
P
ARTS
M
ANUAL
Ag-Bag International, Ltd.
MB10000 July 2003
Appendix A
HyPac System - Parts List
Item#
Part#
Description
Qty.
Remarks
1
1501441
Spring, Extension
1
2
1501440
Link, Quick
3
3
1501439
Pulley
2
4
1100078
Decal, Anchor Indicator
1
5
1120500
Indicator Assembly, Anchor
1
6a
1590049
Cable, Aircraft
1
30-feet
6b
1501442
Sleeve, Micropress crimped
2
7
1120545
Roller, Anchor Indicator
1
8
ref.
Cap Screw, Hex Head
1
1/4-20NC x 2-1/2
9
ref.
Extension, Pulley
1
10
ref.
Cap Screw, Hex
1
1/4-20NC x 2
11
ref.
Washer, flat
2
1/4
12
1540453
Fitting, Hydraulic
2
13
ref.
Grease Whip
1
48-inches
14
ref.
Grease Zerk
5
1/8 FNPT
15
1030090
Pin, Anchor Cylinder - long
1
16
ref.
Grease Whip
1
24-inches
17
1030091
Pin, Anchor Cylinder - short
3
18
ref.
Grease Whip
1
18-inches
19
1060156
Pulley, Anchor Cylinder
11
20
1206079
Cylinder, Head
1
21
ref.
Grease zerk
4
1/8 MNPT
22
ref.
Washer, Spring Lock
8
3/8
23
ref.
Cap Screw, Hex Head
8
3/8-16NC x 3/4
24
ref.
Cylinder, Mount
1
25
ref.
Cap Screw, Hex Head
8
3/4-10NC x 2-3/4
26
ref.
Grease Whip
1
38-inches
27
1541802
Cylinder, Hydraulic Tie Rod
1
28
1060163
Pin, Anchor Cylinder Outlet Pulley
2
29
ref.
Nut, Hex
2
1-8NC Lock
30
ref.
Access Plate Parts
2
30a
ref.
Side Plate - access
ref
30b
ref.
Top Plate - access
ref
30c
ref.
Seat, Anchor
ref
31
1550172
Pin
2
32
ref.
Grease Zerk
2
1/4-28
33
ref.
Grease Whip
1
30-inches
34
1206076
Bolt, Anchor Fairlead
2
