Ag-Bag International, Ltd.
MB10000 July 2003
Appendix A
Forage Dam Feed Table Mount - Parts List
Item# Part# Description Qty. Remarks
1 ref. Cap Screw, Hex 8 5/8-11NC x 3
2 ref. Washer, Lock 8 5/8
3 ref. Anchor Block, Feed Table mounting block 2
4 1080048 Shaft, Feed Table mounting 2
5 1120449 Spacer, Feed Table 2
6 ref. Cap Screw, Hex 6 5/16-18NC x 1-1/4
7 ref. Cap Screw, Hex 11 3/8-16NC x 1-1/2
8 1212013 Strip, Forage dam backup 1
9 1080184 Skirting, forage dam 1 10-feet
10 1212011 Bracket, Forage dam - formed 1
11 ref. Nut, Hex lock 14 5/16-18NC
12 ref. Liner, UHMW 1
13 ref. Cap Screw, counter sunk elevator 8 5/16-18NC x 1-1/4 flat
14 ref. Nut, Hex lock 11 3/8-16NC
15 1080118 Anchor Block, Feed Table Mounting Shaft 2 bottom
Ref 1080216 Anchor Block Set 2 upper and bottom
