Ag-Bag MB10012HyPac User Manual
Page 15
15
P
ARTS
M
ANUAL
Ag-Bag International, Ltd.
MB10000 July 2003
Appendix A
Bag Boom - Parts List
Item#
Part#
Description
Qty.
Remarks
1
Ref.
Nut
2
5/8-11nc
2
Ref.
Nut
1
5/16-18nc
3
Ref.
Capscrew, Hex
1
5/16-18nc x 2
4
Ref.
Capscrew, Hex
2
5/8-11nc x 3
5
Ref.
Pin, Hair Cotter
4
6
Ref.
Pin, Cylinder
4
7
1541739
Cylinder, Hydraulic
1
2 x 20
8
1060144
Pulley, Bag Boom
2
3” steel with bushing
9
1590055
Cable, With Hook
1
5/16 x 23 foot
10
1501622
Spool, bag Boom Cable
1
11
Ref.
Screw, Set
1
3/8-16nc
12
1520339
Gearbox, Right Angle
1
13
Ref.
Nut, Hex
4
7/16-14nc
14
Ref.
Nut, Hex
2
1/2-13nc
15
Ref.
Washer, Flat
2
1/2
16
Ref.
Capscrew, Socket
2
1/2-13nc x 2
17
1540904
Motor, Hydraulic 2 Bolt
1
18
Ref.
Capscrew, Hex
4
7/16-14nc x 1-1/2
19
Ref.
Washer, Flat
4
7/16
20a
1060169
Bag Boom Frame w/extension
1
20b
Ref.
Extension, Bag Boom
1
21
Ref.
Bearing, Bronze
2
22
Ref.
Sleeve, Bearing Spacer
1
23
1060168
Mount, Bag Boom
1
12” and 14”
24
Ref.
Frame, Mounting
1
25
Ref.
Bracket, Cylinder - Boom
2
26
1540097
Cylinder, Hydraulic
1
2-1/2 x 10
27
1201023
Spacer, Bronze
1
5-inch
