Ag-Bag International, Ltd.
MB10000 July 2003
Appendix A
Water Cooling System
Item#
Part#
Description
Qty.
Remarks
1
1501862
Radiator, 500hp
1
2
ref.
Shroud, Fan
1
3
1501888
Fan, 40” 7-Blade
1
4
ref.
Bracket, Fan
1
5
1540059
Clamp, T-bolt
4
6
ref.
Hose Coupler
6
2-1/2
7
ref.
Pipe, Water Return
1
8
1541831
Motor, Hydraulic
1
9
ref.
Adapter, Fan
1
10
ref.
Frame, Engine Skid
1
11
1540061
Clamp, T-bolt
8
3-1/2
12
ref.
Pipe, Water - radiator to reservoir
1
13
ref.
Hose Coupler
4
3
