Ag-Bag International, Ltd.
MB10000 July 2003
Appendix A
Item#
Part#
Description
Qty.
Remarks
1
ref.
Mount, Air cleaner
1
front
2
1540554
Fitting, Hydraulic coupler
3
3
1540637
Fitting, Hydraulic coupler
1
4
1540429
Fitting, Hydraulic coupler
1
5
ref.
Hardline, Hydraulic
1
from cooler
6
1540624
Fitting, Hydraulic coupler
1
7
1540688
Fitting, Hydraulic coupler
1
8
ref.
Hardline, Hydraulic HPTO Manifold
1
Clutch port
9
ref.
Hardlind, Hydraulic HPTO Manifold
1
Lube port
10
ref.
Hardline, Hydraulic HPTO Manifold
1
pump & filter port
11
ref.
Hardline, Hydraulic HPTO Manifold
1
cooler port
12
1540553
Fitting, Hydraulic coupler
2
13
1541960
Filter, Hyd base weldment
1
14
1540673
Fitting, Hydraulic coupler
1
15
ref.
Hose Assembly, HPTO pump pressure
1
16
1541961
Filter, Hyd element
1
17
1540495
Fitting, Hydraulic coupler
2
18
ref.
Hose Assembly, cooler pressure
1
19
1541848
Cooler, oil
1
20
ref.
Hose Assembly, cooler return
1
21
1540537
Fitting, Hydraulic coupler
1
22
1540556
Fitting, Hydraulic coupler
2
23
ref.
Gasket/Shim, Power take off
ref
24
1520751
Power Take Off, Pump drive
1
right
25
1501812
Clutch, HPTO
1
26
ref.
Adapter, Pump
2
27
ref.
Mount, HPTO
1
28
ref.
Kit, Pump coupling & adapter
1
29
1541859
Pump, Hydraulic
1
30
1540555
Fitting, Hydraulic coupler
1
31
ref.
Hose Assembly, HPTO pump suction
1
32
1540553
Fitting, Hydraulic coupler
1
33
1540829
Flange, Hydraulic anchor
1
34
ref.
Nipple, HPTO drain
1
2 x 4 sch. 40 black
35
1540039
Clamp, Hose
2
36
ref.
Hose, HPTO drain
1
37
1500156
Gauge, Sight level & temperature
1
38
1207163
Tank, HPTO Hydraulic oil
1
Hydraulic System HPTO & Pump Drive - Parts List
