2-14

ASUS P8Q67-M DO Series

Enhanced Intel SpeedStep Technology [Enabled]

Allows you to enable or disable the Enhanced Intel

®

SpeedStep Technology (EIST).

[Disabled]

Disables this function.

[Enabled]

The operating system dynamically adjusts the processor voltage and

core frequency which may result in decreased average consumption and

decreased average heat production.

Turbo Mode [Enabled]

This item appears only when you set the previous item to [Enabled].

[Enabled]

Allows processor cores to run faster than marked frequency in specific

conditions.

[Disabled]

Disables this function.

The following three items appear only when you set both the Enhanced Intel SpeedStep

Technology and Turbo Mode items to [Enabled].

Long duration power limit [Auto]

Use the <+> and <-> keys to adjust the value.

Long duration maintained [Auto]

Use the <+> and <-> keys to adjust the value.

Short duration power limit [Auto]

Use the <+> and <-> keys to adjust the value.

Primary Plane Current Limit [Auto]

Use the <+> and <-> keys to adjust the value.

Secondary Plane Current Limit [Auto]

Use the <+> and <-> keys to adjust the value.

2.4.7

Offset Mode Sign [+]

[+]

To offset the voltage by a positive value.

[–]

To offset the voltage by a negative value.

CPU Voltage [Auto]

Allows you to set the CPU voltage. The values range from -0.635V to +0.635V with a 0.005V

interval.

Refer to the CPU documentation before setting the CPU voltage. Setting a high voltage

may damage the CPU permanently, and setting a low voltage may make the system

unstable.
