ASUS P8Q67-M DO Series

1-2

P8Q67-M DO/USB3/TPM

PCIEX16

PCIEX4_1

PCI2

PCI1

LPT

USB1314 USB1112 USB910

USB78

F_PANEL

AAFP

EATX12V

EATXPW

R

CPU_FAN

CHA_FAN

COM1

DP

Lithium Cell

CMOS Power

Super

I/O

AUDIO

ASM
1042

VIA

VT1708S

Intel

®

82579

EPU

KBMS

64Mb

BIOS

SB_PWR

DIS_ME

SPEAKER

CHASSIS

SPDIF_OUT

CLRTC

22.6cm(8.9in)

24.4cm(9.6in)

Intel

®

Q67

DDR3 DIMM_A1 (64bit, 240-pin module)

DDR3 DIMM_A2 (64bit, 240-pin module)

DDR3 DIMM_B1 (64bit, 240-pin module)

DDR3 DIMM_B2 (64bit, 240-pin module)

DVI_VG

A

LAN1_USB12

USB56

USB34

SATA6G_1

SATA6G_2

SATA3G_2

SATA3G_4

SATA3G_1

SATA3G3

LGA1155

TPM IC

1

4

3

2

5

1

6

8

9

10

13 12

14

15

11

16

17

7

Place six screws into the holes indicated by circles to secure the motherboard to the

chassis. DO NOT overtighten the screws! Doing so can damage the motherboard.

Ensure that you install the motherboard into the chassis in the correct orientation. The edge

with external ports goes to the rear part of the chassis.

1.2

Motherboard overview

1.2.1

Motherboard layout

• 2 x USB 3.0 ports (blue) on P8Q67-M DO/USB3/TPM, OR:
• 2 x USB 2.0/1.1 ports (black) on P8Q67-M DO/TPM
