8
49-80151-8
Advance Planning
DUCT FITTINGS Equivalent Quantity Total
Duct Piece Length* Used Length
10" round
to 8" round 5 ft.
Round, 1 ft.
straight (per foot length)
3-1/4" x 10" 1 ft.
3-1/4" x 12" straight (per foot length)
8" Dia. 17 ft.
90° elbow 10" Dia. 24 ft.
8" Dia. 10 ft.
45° elbow 10" Dia. 14 ft.
3-1¦4" x 12" 15 ft.
3-1/4" x 10" 14 ft.
90° elbow
3-1/4" x 10" 8 ft.
3-1/4" x 12" 9 ft.
45° elbow
3-1/4" x 10" 33 ft.
3-1/4" x 12" 36 ft.
ƒÀDWHOERZ
10" round transition
to 3-1/4" x 10" or
3-1/4" x 12" 9 ft.
3-1/4" x 10" or
3-1/4" x 12" to
10" round transition 6 ft.
10" round to 3-1/4" x 10" 16 ft.
3-1/4" x 12" transition 13 ft.
90° elbow
3-1/4" x 10" 9 ft.
3-1/4" x 12" to 10" round 8 ft.
transition 90° elbow
Round 8" Dia. 32 ft.
wall cap 10" Dia. 41 ft.
with damper
3-1/4" x 10" 24 ft.
3-1/4" x 12" wall cap 26 ft.
with damper
Round 8" Dia. 44 ft.
roof cap 10" Dia. 56 ft.
Use this chart to compute maximum
permissable lengths for duct runs to
outdoors.
Note: Do not exceed maximum permissable
equivalent lengths!
Maximum recommended duct
OHQJWKIRUWKHVHKRRGVIHHW
Flexible ducting:
,IÀH[LEOHPHWDOGXFWLQJLVXVHGDOO
the equivalent feet values in the table
VKRXOGEHGRXEOHG7KHÀH[LEOHPHWDO
duct should be straight and smooth
and extended as much as possible.
'R127XVHÀH[LEOHSODVWLFGXFWLQJ
Total Duct Run
Note: Any home ventilation system, such as a
YHQWLODWLRQKRRGPD\LQWHUUXSWWKHSURSHUÀRZRI
FRPEXVWLRQDLUDQGH[KDXVWUHTXLUHGE\¿UHSODFHV
JDVIXUQDFHVJDVZDWHUKHDWHUVDQGRWKHU
naturally vented systems. To minimize the chance
RILQWHUUXSWLRQRIVXFKQDWXUDOO\YHQWHGV\VWHPV
IROORZWKHKHDWLQJHTXLSPHQWPDQXIDFWXUHU·V
JXLGHOLQHVDQGVDIHW\VWDQGDUGVVXFKDVWKRVH
published by NFPA and ASHRAE. When applicable,
install any makeup (replacement) air system in
DFFRUGDQFHZLWKORFDOEXLOGLQJFRGHUHTXLUHPHQWV
Visit GEAppliances.comIRUDYDLODEOHPDNHXSDLU
solutions.
*Actual length of straight duct plus duct
¿WWLQJHTXLYDOHQW(TXLYDOHQWOHQJWKRIGXFWSLHFHV
are based on actual tests conducted
E\*((YDOXDWLRQ(QJLQHHULQJDQGUHÀHFW
requirements for good venting performance with any
ventilation hood.
Hoods Are Equipped
)RU5RXQG'XFW
* Hoods are supplied with a 10"
round transition. A locally
supplied transition is required
for other sizes.
Note: Outlet on top of hood is
8-1/8" x 8".
