Page 40

Hardware options installation 40
c.
Connect the SATA cable to the rear drive cage, secure the cable in the cable clip, and then connect
the cable to the system board.
d.
Install the primary PCI riser cage ("
" on page
10.
Connect the rest of the drive cables required in this drive configuration. For more information, see
)."
11.
Install the drives ("
" on page
CAUTION:
To prevent improper cooling and thermal damage, do not operate the server unless
all bays are populated with either a component or a blank.
12.
Install the access panel (on page
13.
Install the server into the rack ("
Installing the server into the rack
" on page
14.
Installing a 2 SFF rear drive cage option
1.
Power down the server (on page
2.
Remove all power:
a.
Disconnect each power cord from the power source.
b.
Disconnect each power cord from the server.
3.
Do one of the following:
o
Extend the server from the rack (on page
o
Remove the server from the rack (on page
4.
