Scaling the Image
5000PS
With a PostScript file, you can enlarge your printed image from the printer's front-panel
by using the PS scale option, accessed from the Internal RIP Settings menu.
The PS scale feature is useful:
If your software does not support large formats.
If your file is too large for the printer's memory, and you reduce the page size in your
software and then scale it up again using the front-panel option.
To scale your ANSI A PostScript file to:
ANSI B ANSI C Arch C ANSI D Arch D Arch E1 ANSI E Arch E
Use... 129% 200% 210% 258% 282% 352% 400% 419%
5000PS
To scale your ISO A4 PostScript file to:
ISO A3 ISO/JIS A2 OS A2 ISO/JIS
A1
OS A1 ISO/JIS
A0
Use... 129% 200% 210% 258% 352% 400%
