Ink Cartridge Menu
The Ink Cartridge icon looks like this:
If the Ink Cartridge menu is selected, the status of each
of the ink cartridges is shown. If there is a problem with
one or more of the ink cartridges, the front-panel will
display an action message or a error code see
Message Descriptions for more details. If you press
Enter now, you will go to the Ink Cartridge Menu, see
Consumable Menus .
Printhead Menu
The Printhead Menu icon looks like this:
If the Printhead menu is selected, the front-panel
displays the status of each of the printheads. If there is
a problem with one or more of the printheads, the front-
panel will display an action message or a error code
see
Message Descriptions for more details. If you
press Enter now, you will go to the Printhead Menu,
see
Consumable Menus .
