If your external monitor is not detected after pressing
fn
+
f4
, and you have an AMD graphics card,
follow these steps:
1.
Select Computer >More Applications > System > ATI Catalyst Control Center (as
Superuser).
2.
Enter your root password.
3.
Select Display Manager from the right pane.
4.
Click the Detect connected displays button.
5.
Your display settings can be modified by clicking your monitor in the dialog box, and then
selecting the Display properties tab or Multi-Display tab.
6.
After the settings are configured, click Apply, and then click OK. Your computer may require
rebooting.
DisplayPort
The DisplayPort connects a compatible digital display device such as a high-performance monitor or
projector. The DisplayPort delivers higher performance than the VGA external monitor port and
improves digital connectivity.
▲
To connect a digital display device, connect the device cable to the DisplayPort.
NOTE:
Press
fn
+
f4
to switch the image between the display devices connected to the
computer.
NOTE:
To remove the device cable, press down on the connector latch to disconnect it from
the computer.
