C SAN Switch technical specifications
General specifications
lists general specifications for the 16Gb SAN Switch.
Table 11 General specifications
Description
Specification
F_Port, FL_Port, and E_Port
Configurable port types
SFP. Support for speeds of 4/8/16Gb with short wave SFPs
up to 500m (1,640 ft.) and support for speeds of 4/8/16Gb
with long wave SFPs up to 10 km.
Media types
NOTE:
8Gb SFPs support 2/4/8 Gb, and the 16 Gb SFPs
support 4/8/16 Gb
An operating SAN Switch conforms to the emissions
requirements specified by the following regulations:
EMC emissions
•
FCC Rules and Regulations, Part 15 subpart B, Class A
•
CSA C108.8 Class A
•
VCCI Class A ITE
•
CISPR 22 Class A
•
EN55022 Class A
•
AS/NZF 3548: 1995 Class A
•
CNS13438 Class A
•
ICES-003 Class A
•
Korean EMC Requirements
•
BSMI Standard CNS 13438
•
EMC Directive 89/336/EEC
•
EN5022 Level A
•
EN50082-2/EN55024: 1998
EMC immunity
•
IEC 61000-4-2 Severity Level 3 for Electrostatic Discharge
•
IEC 61000-4-3 Severity Level 3 for Radiated Fields
•
IEC 61000-4-4 Severity Level 3 for Fast Transients
•
IEC 61000-4-5 Severity Level 3 for Surge Voltage
•
IEC 61000-4-6 Conducted Emissions
•
IEC 61000-4-11 Voltage Variations
•
EN 61000-4-12 Oscillatory Waves Immunity
•
EN 61000-3-2 Limits for Harmonic Current Emissions
•
EN 61000-3-3 JEIDA
Nonblocking shared-memory switch
System architecture
FC-PH (FC Physical and Signalling Interface standard)
ANSI protocol
FC Class 2, Class 3, and Class F
Modes of operation
2112-byte
Maximum frame size
Less than 2 microseconds with no contention (destination port
is free)
Port-to-port latency
