HP D3000 Disk Enclosures - Manual (Page 45)

Is the enclosure rear fault LED amber?
Actions Possible Reasons Answers
No action required Functioning properly. No
Rear power and UID module might not
be inserted properly, might have a Yes • Be sure that the rear power and UID
module is undamaged and is fully
seated.
damaged connector, or might have
failed.
• Contact an authorized service
provider for assistance.
Is the System Health LED amber?
Possible Solutions Possible Reasons Answer
No action required. System functioning properly. No
Yes •
Be sure that all components are fully
seated.
•
The system might have experienced
a short. Controller firmware might
be corrupted.
• Update controller firmware.
•
The system midplane might need
replacement.
•
Contact an authorized service
provider for assistance.
Is the power supply LED amber?
Actions Possible Reasons Answers
No •
Remove and inspect the AC power
cords from both power supplies and
reconnect them.
•
Power cords not connected or AC
power is unavailable.
• Power supply functioning properly.
•
No action required.
•
Power supply might not be inserted
properly, might have a damaged
connector, or might have failed.
Yes •
Be sure that the power supply is
undamaged and is fully seated.
• Be sure that all pins on connectors
and components are straight.
•
Contact an authorized service
provider for assistance.
Is the I/O module fault LED amber?
Possible Solutions Possible Reasons Answer
No action required. Functioning properly. No
Yes •
Make sure that the I/O module is
seated properly by pressing the I/O
•
The I/O module is locked.
• The I/O module has failed.
module firmly into its bay after the
handle has clicked in place.
•
Other fault condition exists.
CAUTION: Never remove an I/O
module from the chassis while the
status LED is green. Removing an
active I/O module can result in data
loss.
•
Contact an authorized service
provider for assistance.
Diagnostic steps 45
