Architectural paper
The following table lists the printable area for the Architectural paper size system.
The left and right margins are 0.2 in (5 mm) and the leading and trailing edge margins are 0.7 in (17 mm).
Where: .
Printable areas for Architectural paper
Paper
size
Orientation of
paper in
printer
Printable area (width × height) by image orientation
Inches Millimeters
Landscape Portrait Landscape Portrait
Width Height Width Height Width Height Width Height
C Portrait 22.7 17.6 17.6 22.7 576 447 447 576
Landscape 16.7 23.6 23.6 16.7 423 600 600 423
D Portrait 34.7 23.6 23.6 34.7 880 600 600 880
Landscape 22.7 35.6 35.6 22.7 576 904 904 576
E1 Portrait 40.7 29.6 29.6 40.7 1033 752 752 1033
Landscape 28.7 41.6 41.6 28.7 728 1057 1057 728
E Portrait N/A 35.6 46.7 N/A 904 1185
Landscape 34.7 47.6 N/A 880 1209 N/A
Printable area Paper Size Margins – =
Indicates this printable area is available only if you are using the A0+/E+ size format
printer
