ANSI paper
The following table lists the printable area for the ANSI paper size system. The left and right margins are 0.2 in
(5 mm) and the leading and trailing edge margins are 0.7 in (17 mm).
Where:
Printable areas for ANSI paper
Paper
size
Orientation of
paper in
printer
Printable area (width × height) by image orientation
Inches Millimeters
Landscape Portrait Landscape Portrait
Width Height Width Height Width Height Width Height
A Portrait 9.7 8.1 8.1 9.7 245 206 206 245
Landscape 7.2 10.6 10.6 7.2 182 269 269 182
B Portrait 15.7 10.6 10.6 15.7 398 269 269 398
Landscape 9.7 16.6 16.6 9.7 245 422 422 245
C Portrait 20.7 16.6 16.6 20.7 525 422 422 525
Landscape 15.7 21.6 21.6 15.7 398 549 549 398
D Portrait 32.7 21.6 21.6 32.7 830 549 549 830
Landscape 20.7 33.6 33.6 20.7 525 854 854 525
E Portrait N/A 33.6 42.7 N/A 854 1084
Landscape 32.7 43.6 N/A 830 1108 N/A
Printable area Paper Size Margins – =
Indicates this printable area is available only if you are using the A0+/E+ size format
printer
