Specifications – HP NC373F PCI-E Multifunction 1000SX Gigabit Server Adapter User Manual

Page 11

Specifications 11

Specifications

In this section

HP NC373F PCI Express Multifunction Gigabit
Server Adapter specifications

Specification Value

Network Controller Chipset

Broadcom 5708

Bus Type

PCI Express v1.0a

Bus Speed

2.5 GHz

Data Transfer Method

PCI Express Bus Mastering

Power Requirement

Maximum: ~2A @ 3.3V

Standards Supported

IEEE802.3x, IEEE802.3ad, IEEE802.1p, IEEE802.1Q, IEEE802.3z

Dimensions

6.5 x 2.5 in (16.5 x 6.5 cm) without bracket

Connector and Distances

Fiber LC up to 1,804 ft/550m with multimode fiber (50µm/125µm)

Interrupts Supported

Automatically configured

Temperature Range

Operating: 0°C to 55°C (32°F to 131°F)
Storage: -40 to 85°C (-40°F to 185°F)

Relative Humidity (non-condensing) Operating: 10% to 90%

Storage: 5% to 95%

Safety Compliance

CSA Mark (US and Canada)
CE Mark
EN 60590
