9.
Press the OK button on the front panel.
Advance the substrate using the arrows on the front panel. Make sure that the substrate passes in
front of the loading table, as shown.
10.
Pull down the center of the substrate's leading edge to straighten the substrate. Do not attempt to
pull more substrate out of the printer.
NOTE:
If you are loading the take-up reel during printing you do not need to pull the substrate
taut. Tape the substrate to the spindle core when an adequate length of substrate has fed from the
printer after printing begins.
11.
Adjust the position of the core on the take-up reel spindle so that it is aligned with the substrate.
12.
Tape the leading edge of the substrate to the core in the center, then at each side. Make sure that
the substrate is straight.
13.
Press the
OK
button on the front panel. The printer advances the substrate.
38
