Step 2: Connecting to the computer
To connect the computer to the port replicator:
1. Connect one end of the USB cable to the USB 2.0 port (1) on the port replicator.
NOTE: Be sure to connect the USB cable to the USB 2.0 port (1) for computer connection as
indicated in the following illustration. The connection may not function properly if the USB cable
is connected to one of the other USB ports.
2. Connect the other end of the USB cable to a USB port on the computer (2).
NOTE: The location of the USB port on your computer varies by computer series and model.
Step 3: Prevent the computer from sleeping
To ensure that the computer does not initiate Sleep or Standby when the display is closed:
1. Open the Windows Control Panel Power Options page, and then click the Advanced tab.
2. In the Power Buttons section, click Do nothing from the When I close the lid of my portable
computer list, and then click OK.
NOTE: For instructions on accessing the Power Options page, refer to Help and Support on the
computer.
Setting up the USB port replicator 5
