HP Bluetooth Pendant Headphones - Manual (Page 10)

Bluetooth receiver components
Component Description
(1) Mini-USB port Connects a mini-USB cable to charge the receiver.
(2) Audio-out (headphone) jack Connects the audio line-in cable.
(3) Volume up button Increases headphone volume.
(4) Next/fast forward button Plays the next track of a CD or the next chapter of a DVD.
NOTE: This button only works when connected to a Bluetooth-enabled
computer.
(5) Charging light ● Red: The receiver is charging.
● Blinking red: The battery is low.
● Off: The battery is fully charged.
(6) Volume down button Decreases headphone volume.
(7) Receiver status light ● A blinking blue light can indicate any one of the following states:
◦ Power: The receiver is turned on and the light blinks fast 3 times.
◦ Standby mode: After the receiver is turned on, the headphones
go into standby mode and the light blinks slowly until the
headphones are successfully paired with the audio device.
6 Chapter 2 Identifying components
