Brocade Trunking User’s Guide 3-3
Using ISL Trunking
3
Using Web Tools for ISL Trunking
Use Web Tools to view and modify ISL Trunking options through the Trunk Information Tab and
the Port Settings Tab on the Switch Administration interface. For information on how to install and
use Web Tools for the ISL Trunking feature, refer to the Web Tools User’s Guide.
Use the Web Tools Trunk Information tab to view a summary of trunk groups and associated master
and member ports. Table 3-2 describes the headings displayed from the Trunk Information tab.
The following table describes the headings and the tasks you can perform using the Web Tools Port
Setting tab.
Note: ISL Trunking ports always must operate at 2Gb/Sec, setting the speed to 1Gb/Sec prevents
a port from participating in a trunk.
Table 3-2 Trunk Information Tab Description
Trunk Information Tab Description
Trunk Group A numerical number is displayed.
Master Port The associated master port for the group is
displayed.
Member Ports Shows the member ports associated with the
group, separated by a comma.
Table 3-3 Port Setting Tab Features
Port Setting Tab Features Description
Port Number Each port is assigned a number. The port
numbers are displayed under this heading.
Trunking Enable:Disable This allows you to enable or disable ISL
Trunking on a per port basis.
Port Enable:Disable Use this to enable or disable a port.
Port Speed Use this to set the speed of the port to 2Gb/Sec.
