Troubleshooting 60
The available flowcharts include:
• Start diagnosis flowchart (on page 60 )
• General diagnosis flowchart (on page 61 )
• Server blade power-on problems flowchart (on page 63 )
• POST problems flowchart (on page 65 )
• OS boot problems flowchart (on page 67 )
• Server fault indications flowchart (on page 69 )
Start diagnosis flowchart
Use the following flowchart to start the diagnostic process.
Item Refer to
1 "General diagnosis flowchart (on page 61 )"
2 "Power-on problems flowchart (" Server blade power-on problems
flowchart " on page 63 )"
3 "POST problems flowchart (on page 65 )"
4 "OS boot problems flowchart (on page 67 )"
5 "Server fault indications flowchart (on page 69 )"
