Component identification 10

Server A DIMM slots

Server B DIMM slots

Mezzanine connector definitions

Item

PCIe support

Server support

Mezzanine connector 1

x8, Type I mezzanine card only Server A only

Mezzanine connector 2

x8, Type 1 mezzanine card

only

Server B only

A PCIe x8 mezzanine connector supports x16 cards at up to x8 speeds.
