Overview of the Tape Library
SL500 (M852x) Tape Library Installation and User’s Guide — 541531-002
1-10
Capacities
Table 1-1. Cartridge Slot and Tape Drive Capacities
Adding one expansion module
Adding two expansion modules
Adding three expansion modules
Adding four expansion modules
Modules Maximum Number of Tape Drives CAP
Slots
Total
Number of
Slots
2 6 10 14 18
Base Module 30 5 35
20 cartridge upgrade key 50 5 55
Base module plus 1
limited DEM 100 15 115
Base module plus 1
DEM 143 15 158
Base module plus 1
CEM 170 15 185
Base module plus 2
limited DEMs 227 25 252
Base module plus 1
DEM, 1 CEM 254 25 279
Base module plus 2
CEMs 290 25 315
Base module plus 3
DEMs 311 35 346
Base module plus 2
DEMs, 1 CEM 338 35 373
Base module plus 1
DEM, 2 CEMs 374 35 409
Base module plus 3
CEMs 410 35 445
Base module plus 4
DEMs 395 45 440
Base module plus 3
DEMs, 1 CEM 422 45 467
Base module plus 2
DEMs, 2 CEMs 458 45 503
Base module plus 1
DEM, 3 CEMs 494 45 539
Base module plus 4
CEMs 530 45 575
