10 How to Set the Termination
Examples:
Graphic representation of SCSI chains. The devices at the ends of the chains are terminated.
If you previously had only external SCSI devices:
If you previously had only external SCSI devices and the HP drive is the
first internal device in the chain, you may have to remove or disable the
termination on the SCSI card. While most newer SCSI cards adjust
automatically, consult the documentation that came with your card to
find out if you must disable the termination manually.
HP drive
HP drive
HP drive is the only device attached to the SCSI card:
HP drive is installed in the middle of SCSI chain:
SCSI device
Terminated
Not terminated
HP drive is installed at the end of SCSI chain:
SCSI card HP drive
SCSI card
SCSI card
Terminated
Terminated
Terminated
LEAVE jumper
on ACTIVE TERM
pins
REMOVE jumper
from ACTIVE TERM
pins
LEAVE jumper
on ACTIVE TERM
pins
* Disable the termination on a device
SCSI device
*
that was previously the end of the chain.
Terminated Not terminated *
LEAVE jumper
on ACTIVE TERM
pins
* Most newer SCSI cards adjust the termination automatically
External SCSI device SCSI card HP drive
