Status Color Description Item
NIC not used
NOTE: Rear panel NIC can show link
or activity while in standby mode.
Off NIC 2 LED 5
Linked to the network Solid green
Linked with activity on the network Flashing green
No ac power to the system Off Power button and LED 6
System has ac power and is in standby
mode Solid amber
System has ac power and is powered
on Solid green
System Insight Display LEDs
The front panel health LEDs indicate only the current hardware status. In some situations, HP
SIM might report server status differently than the health LEDs because the software tracks more
10 Component identification
