CAUTION:

The processor is designed to fit only one way into the socket. Use the alignment

guides on the processor and socket to properly align the processor with the socket.

5.

Press down firmly until the processor installation tool clicks and separates from the processor,
then remove the processor installation tool.

Processor options

43
