Chapter
1
Introduction
Overview
The Compaq NC3123 Fast Ethernet Server Adapter is a second-generation adapter with PCI
10/100 Wake On LAN (WOL). It features one auto-negotiating RJ-45 port and LED indicators
showing link, activity, and port speed. The NC3123 Server Adapter is a supported option for
selected Compaq ProLiant™ servers.
For the latest functionality, features, and operating system support for this adapter, see the
HP website
Hardware Overview
The Compaq NC3123 Server Adapter uses a PCI 2.1/2.2 bus architecture with the Intel 82559
chipset. The adapter supports emerging standards for system manageability and power
management, such as ACPI and PC99.
Hardware specifications for the NC3123 Server Adapter are provided in Appendix C.
