MAX-CSE Web Interface
31 MAX-CSE/MAX-CSD10 Operation/Reference Guide
If a stream is currently in effect while these parameters are altered, clicking the Apply button will cause
the outgoing stream to stop and then incorporate the new settings without restarting.
Changing the Encoder Profile
1. From the Stream Profiles page, select an option from the Profile drop-down menu. All but the
Custom option contain preset parameters.
2. If you selected the Custom option, select the appropriate options from the Video and Audio
sections.
3. If you wish to change the Stream profile, select between RTP and UDP in the Transport Protocol
drop-down menu.
4. Change the Target Address, Target Port, and Target Audio Port information, if necessary.
5. Set the SAP Settings:
6. To save your changes, click the Accept button. To return to the previously saved settings, click
Cancel.
Encoder Profiles and Parameters
Profiles: Stream Quality: Video Defaults: Audio Defaults: Protocol
Home Theater Maximum • Codec: MPEG-2
• Video In Rate: 6Mbps
• Resolution: D1
• Mode (encoding): CBR • Codec: MP2
• Sampling Rate: 48 KHz
• Effective Rate: 192 Kbps • UDP
High Quality High • Codec: MPEG-2
• Video In Rate: 4Mbps
• Resolution: D1
• Mode (encoding): CBR • Codec: MP2
• Sampling Rate: 48 KHz
• Effective Rate: 192 Kbps • UDP
Good Quality Medium • Codec: MPEG-4
• Video In Rate: 3Mbps
• Resolution: D1
• Mode (encoding): CBR • Codec: MP2
• Sampling Rate: 48 KHz
• Effective Rate: 192 Kbps • RTP
Standard Quality Low • Codec: MPEG-4
• Video In Rate: 2Mbps
• Resolution: D1
• Mode (encoding): CBR • Codec: MP2
• Sampling Rate: 48 KHz
• Effective Rate: 192 Kbps • RTP
VCR Lower • Codec: MPEG-4
• Video In Rate: 1Mbps
• Resolution: SIF
• Mode (encoding): VBR • Codec: MP3
• Sampling Rate: 32 KHz
• Effective Rate: 96 Kbps • RTP
Security Camera Min • Codec: MPEG-4
• Video In Rate: 500 Kbps
• Resolution: SIF
• Mode (encoding): VBR • Codec: MP3
• Sampling Rate: 32 KHz
• Effective Rate: 96 Kbps • RTP
Custom User Dependant • User Selectable:
UDP = MPEG-2 only
RTP = MPEG-2/4
• User Selectable • UDP/RTP
When the a lower quality Encoder Profile is used (Good Quality or lower), the Stream
parameters default to using RTP as a Transport Protocol.
