Installing and Configuring the Tape Drive for the
NonStop NS-Series Integrity Server

5344-2SE Tape Drive Installation and User’s Guide — 546010-001

2 -4

Installation

3. Connect one end of the SAS cable to the left SAS port at the rear of the tape drive.

See

Figure 2-4

for the location.

4. Hand tighten the screws to secure the cable to the unit.

Figure 2-3. Front View of Tape Drive

Figure 2-4. Rear View of Tape Drive

Fan SAS Port Power Connections Fan SAS Port
