50
AXIS Q1755/-E - Technical Specifications
General Casing AXIS Q1755: Metal (zink)
AXIS Q1755-E: IP66-rated, IK10 impact-resistant aluminum enclosure
Processors, memory • ARTPEC-3, 256 MB RAM, 128 MB Flash
• Battery backed-up real-time clock
Power • AXIS Q1755: 8 – 20 V DC max 11,2 W, 20 - 24 V AC max 17,4 VA or Power over
Ethernet IEEE 802.3af Class 3
• AXIS Q1755-E: Power over Ethernet IEEE 802.3af Class 3 or High Power over
Ethernet
Connectors • RJ-45 10BASE-T/100BASE-TX PoE, terminal block for power, I/O terminal block
for two configurable inputs/outputs
• 3.5 mm mic/line in, 3.5 mm line out
• RS485/RS422
• Video out: 3x RCA Y/Pb/Pr (HD), 1x RCA Composite (SD)
Local Storage SD/SDHC memory card slot (memory card not included)
Operating
conditions
• AXIS Q1755: 0 ºC to 45 ºC (32 ºF to 113 ºF) Humidity 20-80% RH
(non-condensing)
• AXIS Q1755-E: -40 ºC to 45 ºC (-40 ºF to 113 ºF) with High Power over
Ethernet, -30 ºC to 45 ºC (-22 ºF to 113 ºF) with Power over Ethernet IEEE
802.3af Class 3
Arctic Temperature Control enables camera start-up at temperatures as low as
-40 °C (-40 °F) with High PoE
Approvals • EN 55022 Class B
• EN 61000-3-2
• EN 61000-3-3
• EN 55024
• EN 61000-6-1
• EN 61000-6-2
• EN 60950-1
• FCC Part 15, Subpart B, Class B
• VCCI, Class B ITE
• C-tick AS/NZS CISPR 22
• ICES-003, Class B
• AXIS Q1755-E: IP66, IK10
Dimensions
(HxWxD)
AXIS Q1755: 58 x 79 x 186 mm (2.3" x 3.1" x 7.3")
AXIS Q1755-E including sunshield: 87/120 x 140/161 x 404 mm
(3.4/4.7” x 5.5/6.4” x 15.9”)
Weight AXIS Q1755: 1.0 kg (2.2 lb) excl. power supply
AXIS Q1755-E: 3.5 kg (7.7 lb.)
Included accessories Connector kits, Installation Guide, CD with installation tools, recording software
and User’s Manual, Windows decoder 1-user license
Video management
software
(not included)
• AXIS Camera Station - Video management software for viewing and recording
up to 50 cameras
• See www.axis.com/partner/adp_partners.htm for more software applications
via partners
• AXIS Q1755-E: wall mount bracket, sunshield, 5 m (16 ft.) Ethernet cable
Optional accessories • YP3040 PT Motor
• AXIS T8412 Installation Display
• AXIS T90A Illuminators
• AXIS Power over Ethernet Midspan 1-port, AXIS T8123 High PoE Midspan
1-Port
• AXIS Camera Station and video management software from Axis’ Application
Development Partners
• AXIS Q1755: Various housings
• AXIS Q1755-E: Mounting accessories
Function/group Item Specification
