35
AXIS Q1755/-E - System Options
For more information, please see Security, on page 31 .
Link-Local IPv4 Address
This is enabled by default and assigns the network cameras an additional IP address for use with UPnP ™ . The camera can
have both a Link-Local IP and a static/DHCP-supplied IP address at the same time - these will not affect each other.
HTTP and HTTPS
The default HTTP/HTTPS port numbers (80 and 443 respectively) can be changed to any port within the range 1024-65535.
This is useful for simple security port mapping, for example.
NAT traversal (port mapping) for IPv4
A broadband router allows devices on a private network (LAN) to share a single connection to the Internet. This is done by
forwarding network traffic from the private network to the “outside”, that is, the Internet. Security on the private network
(LAN) is increased since most broadband routers are pre-configured to stop attempts to access the private network (LAN) from
the public network/Internet.
Use NAT traversal when your network cameras are located on an intranet (LAN) and you wish to make it available from the
other (WAN) side of a NAT router. With NAT traversal properly configured, all HTTP traffic to an external HTTP port in the NAT
router is forwarded to the camera.
Notes:
• For NAT traversal to work, this must be supported by the broadband router. The router must also support UPnP TM .
• The broadband router has many different names: “NAT router”, “Network router“, Internet Gateway”, “Broadband
sharing device” or “Home firewall” but the essential purpose of the device is the same.
Enable/Disable - When enabled, the network cameras attempt to configure port mapping in a NAT router on your network,
using UPnP™. Note that UPnP™ must be enabled in the camera (see
System Options > Network > UPnP).
Use manually selected NAT router - Select this option to manually select a NAT router and enter the IP address for the router
in the field provided.
If a router is not manually specified, the network cameras automatically search for NAT routers on your network. If more than
one router is found, the default router is selected.
Alternative HTTP port - Select this option to manually define an external HTTP port. Enter the port number in the field
provided. If no port is entered here a port number is automatically selected when NAT traversal is enabled.
Notes:
• An alternative HTTP port can be used/be active even if NAT traversal is disabled. This is useful if your NAT router does
not support UPnP and you need to manually configure port forwarding in the NAT router.
• If you attempt to manually enter a port that is already in use, another available port is automatically selected.
• When the port is selected automatically it is displayed in this field. To change this enter a new port number and click
Save.
FTP
The FTP server running in the network cameras enables the upload of new firmware, and user applications. Check the box to
enable the service.
LAN (intranet) WAN (internet)
Broadband
(NAT)
router
ISP
