AXIS Q1755/-E - Product Description

Sun shield

Top cover

Network camera

Bottom cover

Cable cover

AXIS Q1755-E

Part number (P/N) & Serial number (S/N).

The serial number may be required
during the installation.

Cable holes

Network connector (PoE IN)

Alarm output (connected at delivery)

Arctic Temperature Control switch

LED indicator

(disabling not recommended)

I/O cable

Network connector (PoE OUT, connected at delivery)

Network cabe

Caution!
May be hot

Heater
