36 Display Configurations
Display Configurations
Your All-in-Wonder® X1900 graphics card provides dual display
functionality and TV Out. The following table lists the different ways you can
connect displays to your card.
Display
Configuration Connector(s)
Used Comments
Single CRT
display VGA connector OR
DVI-I connector
with DVI-I-to-VGA
adapter CRT- cathode ray tube analog display.
Single DFP
display DVI-I connector DFP - digital flat panel display.
Single TV S-Video Out The S-Video Out can also support a
composite connection via the
S-Video-to-Composite adapter.
Single HDTV
display HDTV Output
Adapter HDTV - High Definition Television
CRT display +
TV VGA connector +
S-Video Out UNSUPPORTED CONFIGURATION
if the CRT display is attached to the
DVI-I connector via the DVI-I-to-VGA
adapter.
CRT display +
HDTV VGA connector +
HDTV (YPrPb)
output cable
DFP display +
TV DVI-I connector +
S-Video out
DFP display +
HDTV DVI-I connector +
S-Video Out to
HDTV (YPrPb)
cable
CRT display +
DFP display VGA connector +
DVI-I connector
CRT display +
CRT display VGA connector +
DVI-I connector
with DVI-I-to-VGA
adapter The DVI-I connector can support a
CRT display using the DVI-I-to-VGA
adapter
