34 Connecting Your Monitors
Connections and Adapters for the All-in-Wonder® X1900 Card
X
Standard VGA Monitor Connector. To connect a VGA monitor
to the DVI-I connector, plug the supplied DVI-I-to-VGA adapter
into the DVI-I connector, then plug your monitor cable into the
adapter.
Y
DVI-I-to-VGA Adapter (if necessary).
Z
DVI-I Backplate Connection. To connect a flat panel, plug the
monitor’s DVI-I connector directly into the DVI-I connection.
[
Honda/VGA adapter (included): To connect a second VGA
monitor, plug the second monitor into the VGA connection on the
Honda/VGA adapter.
\
Honda backplate adapter connection: To enable a second
monitor and provide a connection for TV (S-Video), plug the
Honda/VGA adapter into the Honda backplate connection.
