Using orca – HP Integrity rx4640 Server User Manual
Page 17

Configuring an array 17
Supported procedures
ACU
ORCA
Assignment of RAID level
+
+
Sharing of spare drives among several arrays
+
--
Assignment of multiple spare drives per array
+
--
Setting of stripe size
+
--
Migration of RAID level or stripe size
+
--
Configuration of controller settings
+
--
Expansion of an array
+
--
Creation of multiple logical drives per array
+
--
Using ORCA
1.
Power up the server.
POST runs, and any array controllers that are in the server are initialized one at a time. During each
controller initialization process, POST halts for several seconds while an ORCA prompt message
appears.
2.
At the ORCA prompt, do one of the following:
o
If you are connected using a headless console, press the Esc+8 key combination.
o
In all other situations, press the F8 key.
The ORCA main menu appears, enabling you to create, view, or delete a logical drive.
To create a logical drive using ORCA:
1.
Select Create Logical Drive.
