CP-150 User Manual --- Page 42
A.15 KEYBOARD Interface Connector (CN11)
Table A-15: KEYBOARD Interface Connector
Pin Signal
1 KBCLK
2 KBDATA
3 N/C
4 GND
5 VCC
A.16 MOUSE Interface Connector (CN9)
Table A-16: MOUSE Interface Connector
Pin Signal
1 MSCLK
2 MSDATA
3 N/C
4 GND
5 VCC
A.17 COM2 Interface Connector (CN13)
Table A-17: COM2 Interface Connector
Pin Signal
1 DCD
2 RX
3 TX
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9 RI
10 N/C
