CP-150 User Manual --- Page 3
1.2 Features
• Portable enclosure for 6U CompactPCI ® boards
• 6-slot 6U CompactPCI ® backplane
• 15” Touch LCD monitor built-in
• Supports computer telephony specification (PICMG 2.5)
• Built-in slim CD-ROM, FDD and Keyboard
• Supports one 3.5” HDD
• Supports 400 W ATX power supply
• High impact resistant plastic and high strength aluminum plat chassis
• Space for peripheral kit in any application
• Easy access for maintenance
• Vibration and shock resistant
• Build-in Mechanical type keyboard in 108 keys, with touch pad point device.
1.3 Specifications
1.3.1 General
• Construction: Aluminum frame and galvanized sheet steel
• 6-slot space (24 TE), including one system slot and five peripheral slots
• "Hot swappable” platform complies with PICMG 2.1 R 2.0 Hot Swap
Specification
• Dimensions (W x H x D, mounting flanges not included):
400 x 291 x 223 mm (15.7" x 11.5" x 8.8")
• Weight: 11.2 kg (24.7 lb)
• Operating temperature: 0 ~ 45° C
• Storage temperature: -20° C ~ 60° C
• Relative humidity: 20 ~ 90% @ 40° C, non-condensing
• Operating altitude: 0 ~ 3,048 meters (0 ~ 10,000 feet)
• Storage/transit altitude: 0 ~ 12,190 meters (40,000 feet)
• Shock: 10 G (operating); 30 G (storage/transit)
• Random vibration: 1.0 Grms (operating)
1.3.2 Fans
• Air flow: One 113-CFM fan (inlet) and one 41-CFM fan (outlet)
• Rated fan speed: 3700 rpm (inlet), 3000 rpm (outlet)
• Life expectancy: 70,000 hours @ 40° C (inlet), 50,000 hours @ 25° C (outlet)
1.3.3 Power Supply
• Input: 100~240 V
AC
@ 50~60 Hz with auto switching capability -- PFC (Power
