A.13 FDD Interface connector (CN6)
Table A-13: FDD Interface Connector
Pin Signal Pin Signal
1 +5V 14 STEP#
2 INDEX# 15 GND
3 +5V 16 WDATA#
4 DS0# 17 GND
5 +5V 18 WGATE#
6 DSKCHG# 19 GND
7 N/C 20 TRK0#
8 N/C 21 GND
9 N/C 22 WRTPRT
10 MTR0# 23 GND
11 N/C 24 RDATA#
12 DIR# 25 GND
13 DRVEN0 26 HDSEL#
A.14 VGA Interface connector (CN10)
Table A-14: VGA Interface Connector
Pin Signal
1 BLUE
2 GND
3 GREEN
4 GND
5 RED
6 GND
7 HSYNC
8 VSYNC
9 GND
10 GND
11 DDCSDA
12 DDCCLK
13 GND
