PREPARATION
PREP
ARA
TION
20
STAND INSTRUCTIONS
(For 19/22LE5300, 22LE5500)
ᯫ Image shown may differ from your TV.
INSTALLATION
!
NOTE
Ź
When assembling the desk type stand,
make sure the screws are fully tightened (If
not tightened fully, the TV can tilt forward
after the product installation). Do not over
tighten.
1
Carefully place the TV screen side down
on a cushioned surface to protect the
screen from damage.
2
Assemble the parts of the STAND BODY
with the STAND BASE of the TV.
3 Assemble the TV as shown.
4
Install the 4 screws into the holes shown.
DETACHMENT
1
Carefully place the TV screen side down on
a cushioned surface to protect the screen
from damage.
2 Remove the screws from the TV.
3 Detach the stand from TV.
STAND BASE
STAND BODY
M4 x 14
