72
Aviom A-16R and A-16CS User Guide
SOX
1111
0000
(F0H)
Start of Exclusive
Manufacturer’s
ID
0000
0000
(00H)
Aviom Manufacturer’s ID
Byte 1
0000
0001
(01H)
Aviom Manufacturer’s ID
Byte 2
0100
0101
(45H)
Aviom Manufacturer’s ID
Byte 3
Family ID
0000
0000
(00H)
(A16 Family)
Product ID
0000
0000
(00H)
(A-16R Product)
Device ID
0000
0000
(00H)
(expansion)
Msg. Type
0000
0000
(00H)
Message Type = MIDI_ALL_
PRESETS_MSG
Msg. Descriptor
0000
0000
(00H)
Message Descriptor Byte 1
(expansion)
0000
0000
(00H)
Message Descriptor Byte 2
(expansion)
0000
0000
(00H)
Message Descriptor Byte 3
(expansion)
0000
0000
(00H)
Message Descriptor Byte 4
(expansion)
0000
0000
(00H)
Message Descriptor Byte 5
(expansion)
0000
0000
(00H)
Message Descriptor Byte 6
(expansion)
Preset ID
0001
0000
(10H)
Nibblized First Preset ID
(MSB)*
0001
0000
(10H)
Nibblized First Preset ID
(LSB)*
Preset Data
...
...
112 consecutive bytes
containing info for one preset
Preset
Checksum
0001
nnnn
-
Nibblized Preset Data
Checksum (MSB)
0001
nnnn
-
Nibblized Preset Data
Checksum (LSB)
Preset Trailer
0100
0000
(40H)
Indicates end of a given preset
Padding
...
...
500 consecutive bytes of the
pattern 00H
