Aviom A-16CS - Manual (Page 15)

5
A-16R
A-Net Mixer
Phones
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Mix In
Remote
Midi Off
Local
Midi On
7 Solo button
8 Mute button
9 Channel Pan control and LEDs
10 Channel Volume control and LEDs
11 A-Net Active LED
12 Mix In volume control
13 Bass tone control
14 Treble tone control
15 Master volume control
16 Remote/Local MIDI on/off switch
17 Headphone output
A-16R Components - right side
7
8
9
10
12 13 11 14 15 16
17
