28
Aviom A-16R and A-16CS User Guide
• The R
ECALL
and G
ROUP
buttons will both flash when
held down simultaneously. This is the Save Mode, as
indicated by the connecting graphic above the two
buttons on the front panel.
• When a Preset is saved, all sixteen Channel buttons
will flash briefly to confirm the Preset save operation.
• The S
OLO
button has one LED. It will light when
pressed, indicating that the selected Channel or Group
is now being auditioned with all other Channels being
muted.
• The M
UTE
button has no LED in it. Pressing the M
UTE
button with a Channel selected will silence the Channel
and cause the Channel’s lower ( yellow) LED to light.
There is also one special button combination, the R
ECALL
button
followed by the M
UTE
button. When used together this combination
serves a twofold function:
• If there is a sudden change in the audio volume coming
through the monitor system, this button combination
silences all audio channels instantly.
• When starting from scratch to create a new mix, use
this function to set all sixteen channels to zero volume
and all channel pans to the center setting.
A-16R
A-Net Mixer
Phones
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Mix In
Remote
Midi Off
Local
Midi On
Note: The text on the right side of the label strip reads
“In Recall Mode All Volumes Zero” as a reminder
that this function is always available.
Making Changes to Channel Settings
The A-16R Personal Mixer has one set of common controls used
for mix editing. A simple convention is used: to make a change to a
Channel, first select it. Then the Channel is available for editing.
On the Personal Mixer you can change:
• Volume
