60
Aviom A-16R and A-16CS User Guide
flash
Press any A-16R button to acknowledge the transfer status message
and return the A-16R to normal operation.
Loading an All Preset File via MIDI
As when loading a single Preset via SysEx, to load an All Preset data
file the A-16R must first be placed into MIDI Recall Mode.
The A-16R will remain in MIDI Recall until a valid A-16R MIDI
message is received, or until another front panel button is pressed to
exit MIDI mode. MIDI SysEx information for other manufacturer’s
devices will pass through the A-16R and be ignored.
To load an All Preset data file via SysEx:
1. Set the A-16R front panel R
EMOTE
/L
OCAL
switch to the
L
OCAL
position.
2. Press the R
ECALL
button. The R
ECALL
button LED
flashes.
3. Press the S
OLO
button to arm the A-16R for MIDI
reception. The LED in the S
OLO
button will blink.
4. Send the All Preset SysEx data file from your MIDI
storage device.
5. The sixteen Presets are loaded into the A-16R internal
memory sequentially.
6. The Mute LEDs will serve as a progress bar. The
LEDs will light in order from 1 to 16 as each Preset is
received successfully.
When the All Preset SysEx file transfer is complete, the system
will display a status message to confirm that the data was received
properly. Two messages are possible:
• Valid Data Received - all yellow Mute LEDs will flash
• Invalid Data or MIDI Error - all red Channel LEDs will
flash
Press any A-16R button to acknowledge the transfer status message
and return the A-16R to normal operation.
Exit MIDI Mode
You can exit an All Preset SysEx load operation by pressing any A-16R
front panel button, or by changing the position of the Remote/Local
switch. Presets that have been successfully received prior to exiting
the SysEx recall mode will be preserved in the internal memory of
