Line keys and softkeys – Aastra Telecom 6757I User Manual

Page 105

Model 6757i IP Phone User Guide

Line Keys and Softkeys

Configuring Group Call Pickup (GCP) Key (for Sylantro Servers)

Use the following procedure to configure Group Call Pickup on the 6757i IP Phone. The

procedure shows the softkey screens as an example.

1. Click on Operation->Softkeys and XML.

or
Click on Operation->Expansion Module .

Softkeys

2. Select from “Key 1” through “Key 10” on the Top keys.

or
Select from "Key 1" through "Key 20" on the Bottom keys.

3. In the “Type” field, select Directed Call Pickup.

4. In the "Label" field, enter a label to apply to this Group Call Pickup key.

5. In the “Value” field, enter groupcallpickup.

6. In the "Line" field, select the line for which to apply the Group Call Pickup configuration.

Valid value are 1 through 9.

Aastra Web UI

Note:

A ring group must be configured on the Sylantro Server in order for a GCP

softkey to function.
