9
Getting familiar with the appliance
In this section we describe the control panel, elements
and displays.
These instructions apply to more than one cooktop, your
appliance might vary slightly.
Page 2 contains a list of models and dimensions.
Control panel
Touch control zone
When you touch a symbol, the corresponding function
will be activated.
NOTICE: Always keep the touch control zones clean
and dry. Moisture and dirt can affect proper functioning.
0O0GG $MFBO-PDL
$IJME-PDL
NJO
@
5JNFS
Display icons
> Cleaning protection on
D Child lock on
V Kitchen timer on
‰‰ Timer value
q Cook time function on
¶ Cook time set on lit element
‰ . Power level ‚ - Š
Ready ‹
Residual heat • / œ
ð Dual element
à Bridge element
Touch keys
On/Off
Main power switch
Clean Lock/
Child Lock
Cleaning protection / Child safety
Timer Cook time function
à Bridge element
ö Additional heating elements
$ Select cooking element
0 - 9 Temperature levels
A @ Step temperature level down/up in steps
of 0.5
