English 10
4. Guide the unit straight back into the cabinet cutout.
Note: Be careful not to crimp the flexible conduit
between the oven and the cabinet back wall. If
necessary, guide the flexible conduit into the wall or
cabinet access hole so it doesn’t prevent the unit from
being pushed all the way into the cabinet opening. The
oven should be straight and level, not crooked.
5. Install the oven bottom trim while the door is removed
and the unit is in place. (Do not push the unit all the
way in, leave about 1 inch extending from the front of
the cabinet). Use two of the screws provided in the red
bag included with the trim piece.
3. Push the unit straight in until the oven trim is flush with
the front of the cabinet trim.
4. Install supplied screws through tap holes in trim. (2
screws for single ovens, 4 screws for double/combo
ovens).
To replace the oven door:
1. Align holes in trim ends with holes at bottom of oven.
2. Insert screws and tighten firmly. Do not overtighten.
1. Hold the door firmly in
both hands.
2. Hold the door at a 30º
angle from the closed
position and insert
hinges into the slots.
You may need to rock
the door forward and
backward slightly to
seat the hinge feet.
3. The door may need to
be removed and re-
inserted until the
hinges sit correctly in
the slots.
4. Open door all the way
to expose hinges,
levers, and slots.
5. Push levers forward
and down until seated
on the bracket.
6. Close and open door
slowly to be sure it is
correctly and securely
in place. Door must be
straight, not crooked.
