MULTI-TASKER™
400-0082-005 19
19
MT104-100/103 MAIN MENU
PRESS KEY TO SELECT
1: CONTROL
2: SETUP
3: STATUS
4: HELP
ESC: GO BACK
KEY =
MT104-100/103 EXPANDED MENUS
1. CONTROL
CONTROL: FOR THIS CARD
1: SELECT (Select Card/Group for Control)
CURRENT SELECTION: THIS CARD
0: This Card
1: Group 1
2: Group 2
3: Group 3
4: Group 4
5: Group 5
6: Group 6
7: Group 7
8: Group 8
ESC: GO BACK
2: SAVE (Save Card Settings)
ON 1 C03
SAVE THIS SETTING?
1: YES
2: NO
3: CLEAR (Set to Defaults)
RESET CARD TO FACTORY DEFAULT:
* Switch to Input 1
1: YES
2: NO
4: SWITCH (Switch I/O Connection)
SWITCH: (INPUT1)
1: INPUT1
2: INPUT2
3: INPUT3
4: INPUT4
5: INPUT5
6: INPUT6
7: INPUT7
8: INPUT8
ESC: GO BACK; S:STATUS
ESC: GO BACK
2: SETUP
SETUP:
1: SET GROUP ID
SET GROUP ID: (NONE)
1: ASSIGN GROUP ID+
2: DELETE GROUP ID+
ESC: GO BACK
3: STATUS
Equivalent to the [C] command.
Returns the card status.
4: HELP
Equivalent to the [HELP] command.
Displays a list of commands available for the
MT104-100/103 along with a brief
description.
ESC
Returns to the parent menu.
7.4.5 MENU MODE EXAMPLES
All MENU MODE examples assume an
MT104-100 is installed in slot #4. Start by
clicking the mouse in the Terminal window.
Press ENTER and a list of available cards will
be displayed.
NOTE When entering numeric values (not
selecting menu items) the system may
echo each character as it is typed.
