PATH OPTION
[OFF…..P]: Sets Path
This command will set the path for the output,
but it is not active until the switch command,
[SW], is executed. Commands ending in "P" are
not executed immediately. The path for outputs
on multiple cards or the same card can be
loaded.
Command Format: [OFFmCnUiP]
m = Input Number that is ON (optional)
n = card ID (n = slot # from 1 to max slots)
P = path
Example:
There are two MT104-100/103 cards in slots 6
and 7. Disable Input 1 of card 6 and Input 3 of
card 7 simultaneously using the following
commands.
[OFF1C6P]
[OFF3C7P]
[SW]
FEEDBACK OPTION
If "F" is included, use the [OFFmCnUiPF]
command or the [OFFmCnUiFP] command.
[OFF…..F]: Feedback
After processing a command, an OK or ER will
be returned as feedback if "F" is included at the
end of a command string.
Example:
[OFF1C2F]: if path is not set
[OFF1C2PF]: if path is set
9. […S] – Save
This command will save the configuration
command being sent in memory. When
sending the command [ON1C4S], after reset or
power up, Output 1 on C4 will be enabled.
10. […F] – Feedback
After processing a command, an OK or ER will
be returned as feedback if "F" is included at the
end of a command string.
11. […P] – Path
This command will set the path for the output,
but it is not active until the switch command,
[SW], is executed. Commands ending in "P" are
not executed immediately. The path for outputs
on multiple cards or the same card can be
loaded. See examples in ON and OFF
commands.
12. [SW] – Switch
The switch command immediately connects
inputs and outputs previously set with the path
command. The command switches all paths set
on this card and all other cards in the enclosure
Example:
[ON1C6P]
[ON3C7P]
[SW]
13. [SIG] – MT104-100 Only
The Signal Present command tests for the
presence of a signal. After sending the
command, the feedback will be either "1"
signifying a signal is present, or a "0" indicating
no signal was detected.
Command Format: [SIGCnUi]
Cn = Card ID (n = slot # from 1 to max slots)
Ui = Unit ID (i = # from 0 to 9)
Example:
To check for the presence of an input signal on
card 4, send the command [SIGC4] and verify
feedback of "1" or "0".
