Andrew OM24SNG-RC - Manual (Page 25)

Antenna Dimensions
25 Specifications
Antenna Clearance Envelope and Center of Gravity - Side View
16’-10”
10’-0”
7’-7”
Elevation
and
Articulation
Axis
1”
11’-4”
8’-8”
6’-11”
Elevation
and
Articulation
Axis
8’-4”
6”
5”
Azimuth Axis
1’-6”
3’-1”
2’-0”
Note:
Antenna Shown
at 65° Elevation
7’-7” R
4’-9” R
Azimuth
Axis
1’-8” R
Elevation
and
Articulation
Axis
Antenna Clearance Envelope - Top View
1.5”
1.5”
Boom Stop (2)
(2” x 3” x 1/4” x 6” lg)
Azimuth
Axis
Elevation
and
Articulation
Axis
1”
10’-7”
15”
8.5° 7’-6”
6”
67.7°
Antenna Clearance Envelope - Side View
Note:
Antenna Shown
at 0° Elevation
X
